PRO SW3000XLS AND PRO SW3200XLS DUAL COMBINATION. (SW3000XLS DATA COVERAGE FOLLOWS SW3200XLS DATA)
PRO SW3200XLS:



Description:

PRO SW-3200XLS (For Gates Up to 16 Feet AND 650 lbs)

Improvements:
Reintroduction of product
Increased operating speed by 10%
NEW rev-counter board with reed switch technology
IMPROVED front mount and scraper seal design
Solar Compatible


Technical Specs:
Mechanical:
The GTO/Access© control board can be programmed for pull-to-open or push-to-open.
Operating temp: -5 F (-21C) to +160 F (71 C).
Opening time: From 15 to 20 seconds.
Range of arm stroke: is up to 16" (41 cm).
Operator length: with arm fully retracted is 40.25" (102 cm), mounting point to mounting point.
Shipping Weights: 3200XLS Kit 28 lbs. (18 kg); Meets UPS shipping standards.

Electrical:
12 Volt DC / 7.0 amp hour, sealed, rechargeable battery (included). Battery charge is maintained by a 18 VAC 40 VA output, transformer.
Powered by a reliable 12 Volt DC motor, 16:1 planetary gear drive system.
Charging regulated circuit on control board. "Sleep draw" is 15 mA; "active draw" is 6 to 14 amps.
Warranty:  2 Year (Single-Family Residential Application Only)

Features

 Second operator arm for PRO SW-3000XLS dual gate opener.

PRO SW-3200XLS (For Gates Up to 16 Feet AND 650 lbs)

Improvements:
Reintroduction of product
Increased operating speed by 10%
NEW rev-counter board with reed switch technology
IMPROVED front mount and scraper seal design
Solar Compatible

Mechanical:
The GTO/Access© control board can be programmed for pull-to-open or push-to-open.
Operating temp: -5 F (-21C) to +160 F (71 C).
Opening time: From 15 to 20 seconds.
Range of arm stroke: is up to 16" (41 cm).
Operator length: with arm fully retracted is 40.25" (102 cm), mounting point to mounting point.
Shipping Weights: 3200XLS Kit 28 lbs. (18 kg); Meets UPS shipping standards.

Electrical:
12 Volt DC / 7.0 amp hour, sealed, rechargeable battery (included). Battery charge is maintained by a 18 VAC 40 VA output, transformer.
Powered by a reliable 12 Volt DC motor, 16:1 planetary gear drive system.
Charging regulated circuit on control board. "Sleep draw" is 15 mA; "active draw" is 6 to 14 amps.
Warranty:  2 Year (Single-Family Residential Application Only)

---------------------------------------------------------------------------------------------------

PRO SW-3000XLS:

Description:
PRO SW-3000XLS (For Gates Up to 16 Feet AND 650 lbs)

Improvements:

Reintroduction of product
Increased operating speed by 10%
NEW rev-counter board with reed switch technology
IMPROVED front mount and scraper seal design
Solar Compatible

Technical Specs:
Mechanical:
The GTO/Access© control board can be programmed for pull-to-open or push-to-open.
Operating temp: -5 F (-21C) to +160 F (71 C).
Opening time: From 15 to 20 seconds.
Range of arm stroke: is up to 16" (41 cm).
Operator length: with arm fully retracted is 40.25" (102 cm), mounting point to mounting point.
Shipping Weights: 3000XLS Kit 39 lbs. (18 kg); Meets UPS shipping standards.

Electrical:
12 Volt DC / 7.0 amp hour, sealed, rechargeable battery (included). Battery charge is maintained by a 18 VAC 40 VA output, transformer.
Powered by a reliable 12 Volt DC motor, 16:1 planetary gear drive system.
Charging regulated circuit on control board. "Sleep draw" is 15 mA; "active draw" is 3 to 7 amps.


Features


Full systems capable "add on ready" heavy duty control board includes adjustable obstruction sensing, gate sequencing and autoclose settings (0-120 seconds).

Easy transmitter programming with the touch of a button.

Includes battery backup, 318 MHz radio receiver, entry transmitter, AC transformer and all necessary mounting hardware for a post mounted installation, 16" (40.6cm) total offset.

Warranty:  2 Year (Single-Family Residential Application Only)

Full systems capable "add on ready" heavy duty control board includes adjustable obstruction sensing, gate sequencing and autoclose settings (0-120 seconds).

Easy transmitter programming with the touch of a button.

Includes battery backup, 318 MHz radio receiver, entry transmitter, AC transformer and all necessary mounting hardware for a post mounted installation, 16" (40.6cm) total offset.

Warranty:  2 Year (Single-Family Residential Application Only)
